IC694MDL241 GE Fanuc PACSystem RX3i Voltage Discrete Input Module

GE Fanuc RX3i IC694MDL241: 16-Point Universal Input Module

Description

Versatile 24V AC/DC input module for RX3i PLC systems. Features 16 isolated points with LED status indicators and active diagnostics for real-time fault detection.

Technical Specifications

• Brand/Model: GE Fanuc RX3i IC694MDL241
• Input Points: 16 (non-polarized)
• Input Current: 7mA
• Voltage Range: 24V AC/DC universal
• Isolation Ratings:
  • Field to backplane: 250V AC
  • Field to frame: 1500V AC
• Power Consumption:
  • 80mA @ 5V DC (backplane)
  • 125mA @ 24V DC (isolated bus)
• Output Type: Triac
• Indicators: 16 green LEDs (point status)

Installation Notes

• Mounts in any RX3i I/O slot
• Backplane-powered operation
• Common power terminal for grouped inputs
• Compact design saves panel space

Compatibility

Works with:

• RX3i PacSystems
• Thumb switches & sensors
• 24V AC/DC control devices

Package Contents

• IC694MDL241 Input Module
• Installation documentation

Warranty & Shipping

• 12-month manufacturer warranty
• Global delivery via FedEx, UPS, DHL

FAQ

Q: Is this module AC or DC?
A: Both – accepts 24V AC or DC signals

Q: What’s the input sensitivity?
A: Detects inputs as low as 7mA

Q: How are faults indicated?
A: Through active diagnostics with configurable alarms

Q: Wire polarity requirements?
A: None – non-polarized design
