IC693ALG391-16-Ch | GE Fanuc Analog Output Module Series 90-30

GE Fanuc IC693ALG390: 2-Channel Analog Voltage Output Module

The GE Fanuc IC693ALG390 is a high-performance analog output module for Series 90-30 PLCs. It delivers precise voltage control for industrial automation. This reliable IC693ALG390 module is perfect for driving actuators and control systems.

Technical Specifications

Brand: GE Fanuc
Series: Series 90-30
Model: IC693ALG390
Type: Analog Voltage Output Module
Channels: 2
Output Range: -10V to +10V DC
Resolution: 2.5 mV (1 LSB)
Accuracy: ±5 mV @ 25°C (77°F)
Update Rate: 5 ms (both channels)
Isolation: 1500 VAC
Power Consumption: 32 mA @ +5V, 120 mA @ +24V
External Supply: 18-30 VDC
Operating Temperature: 0 to 60°C (32 to 140°F)
Offset Drift: < 1 mV

Installation & Setup

Install in any Series 90-30 baseplate slot. Use shielded cables for best performance. Connect shield to GND terminal. Set DEF0 jumper for desired behavior on CPU stop.

Compatibility

Designed for seamless integration with all Series 90-30 PLC CPUs. Perfect for closed-loop control and instrument signaling.

Warranty & Shipping

This product includes a 12-month warranty. We ship quickly worldwide via FedEx, UPS, and DHL.

FAQ

• What does this module do?
  It converts digital commands from the PLC into precise analog voltage signals (-10V to +10V).
• How many devices can I control?
  You can control two independent devices with the two output channels.
• What power supply does it need?
  It uses the PLC’s internal +5V power and requires an external 18-30 VDC supply for output power.
• What happens if the PLC stops?
  You can configure outputs to hold their last value or go to 0V using the DEF0 jumper.
• Is electrical noise protection included?
  Yes, it has 1500V isolation between the logic and field sides to protect against noise.
