Bently Nevada | 330930-065-03-CN 3300 NSv Extension Cable

Bently Nevada 3300 NSv Extension Cable: Precision Connectivity for Industrial Monitoring

Extend your sensor reach with the 330930-065-03-CN extension cable from Bently Nevada. Engineered for critical machinery monitoring systems, this 6.5m FEP-insulated coaxial cable ensures signal integrity in extreme environments. Perfectly pairs with 3300 XL NSv Proximitor Sensors for vibration and position measurement.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 NSv Extension Cable (Full Suffix: 330930-065-03-CN)
• Cable Length: 6.5m / 21.3ft (Code: 065)
• Connector Type: Gold-plated brass with protector (Code: 03)
• Approvals: Country-specific certifications (Code: CN)
• Operating Temp: -51°C to +177°C (-60°F to +351°F)
• Resistance: 0.220 Ω/m (center), 0.066 Ω/m (shield)
• Capacitance: 69.9 pF/m typical
• Impedance: 75 Ω coaxial
• Material: FEP-insulated with optional SST armor

Core Performance Features

• Max Field Wiring: 305m (1,000ft) to monitor
• Tensile Strength: 220N (50lb) at all connection points
• Shipping Weight: 1.5kg
• Warranty: 12 months

Installation Guide

• Total sensor system length = Probe length + Extension cable length
• Recommended gap setting: 1.0mm (40 mils)
• Use 0.2-1.5mm² (16-24 AWG) shielded triad cable for field wiring
• Maximum linear range: 1.5mm (60 mils)

Certification & Shipping

• Global Shipping: FedEx, UPS, DHL
• Made in U.S.A.

FAQ

• Q: Can I use this in high-temperature environments?
  A: Yes, rated for continuous operation at +177°C (351°F)
• Q: What’s the total system length limit?
  A: Sensor + extension cable + field wiring ≤ 305m
• Q: Is armored version available?
  A: Optional SST armor (specify when ordering)

Download the full installation manual for your 3300 NSv system: Click Here

This 330930-065-03-CN extension cable ships worldwide with 12-month quality guarantee.
