Bently Nevada | 3300 XL 8mm Reverse Mount Probe 330105-02-12-30-02-00

Core Specifications

Brand: Bently Nevada | Model: 330105-02-12-30-02-00 | 1-Year Warranty

Quick-View Details

• Length: 3.0 meters (standard cable)
• Connector: ClickLoc® coaxial (gold-plated)
• Size: 20.4×22.2×3.7 cm | Weight: 0.23 kg

Suffix Code Guide for 330105-02-12-30-02-00

• -30: 3.0m probe length
• -02: Miniature ClickLoc® connector
• -00: No agency approvals required

Critical Performance Data

• Resistance: 8.17Ω ±0.50 at 3.0m
• Threads: 3/8-24 UNF (max 0.563″ grip)
• Temp Range: -52°C to +260°C

Certifications & Safety

• Hazardous Areas:
  • Zone 0: Ex ia IIC T1-T5 Ga
  • Zone 2: Ex nA/ec IIC T1-T5 Gc
• Groups: A/B/C/D (Gases) | E/F/G (Dust)

Temperature Ratings

• EPL Ga/Gc: T1(+232°C) to T5(+40°C)
• EPL Dc: T90°C to T280°C

Additional Features

• Seal: Viton® O-ring (humidity stable at 93% RH)
• COO: Certificate of Origin available
• Cable Strength: 330N pull resistance

Document Download Here: 3300 XL 8 mm Proximity Transducer System Datasheet
