Bently Nevada – 3300 XL 8mm – 330130-070-02-05 – Extension Cable

Bently Nevada 330130-070-02-05 Extension Cable: Heavy-Duty & Certified

Key Features

Model 330130-070-02-05 | 7.0 meters long (22.9 ft) | 1-year warranty
Armored design (103g/m) | Weight: 0.618kg | Works from -40°C to +125°C
Certified safe: CSA, ATEX, IECEx approvals

Easy Installation

• Fits 16-24 AWG wires | Max distance: 305 meters (1,000 ft)
• Includes silicone tape (alternative to protectors)
• Warning: Don’t use tape near turbine oil

Strong Performance

• 330N pull strength (CableLoc design)
• Stable power: -17.5V to -26V DC
• Low sensitivity: <2mV change per volt

Technical Specs

• Core resistance: 1.54Ω ±0.23
• Jacket resistance: 0.46Ω ±0.09
• Capacitance: 69.9 pF/m
• Calibrated for AISI 4140 steel targets

Extra Protection

• Viton® O-ring (heat-resistant seal)
• Optional FluidLoc cable stops leaks
• Tested at 93% humidity for 56 days
