Bently Nevada 3300 NSv Proximity Sensor | 330904-08-10-10-02-05

Bently Nevada 330904-08-10-10-02-05 3300 NSv Probe

Discover the high-performance Bently Nevada 3300 NSv proximity probe, part number 330904-08-10-10-02-05. This unit is new and original, shipped in factory-sealed packaging. It includes a solid 12-month warranty for your peace of mind. We offer quick global shipping via FedEx, UPS, and DHL.

Key Product Specifications

• Manufacturer & Series: Bently Nevada 3300 NSv
• Complete Model: 330904-08-10-10-02-05
• Linear Measurement Range: 1.5 mm (0.25 to 1.75 mm)
• Voltage Output Range: Approximately -1 to -13 Vdc
• Sensitivity (Scale Factor): 7.87 V/mm (200 mV/mil)
• Excellent Linearity: Deviation less than ±0.06 mm
• Wide Frequency Response: 0 to 10 kHz
• Extended Operating Temperature: -52°C to +177°C
• Electrical Resistance (1m cable): 4.2 ± 0.5 ohms

Physical Design & Durability

• Probe Case Material: Robust AISI 304 Stainless Steel
• Case Thread Size: M8 x 1.0 mm
• Overall Case Length: 100 mm
• Probe Tip Material: Chemical-resistant Polyphenylene Sulfide (PPS)
• Cable Type & Length: 75 Ω coaxial, 1.0 meter total length
• Connector: Miniature coaxial ClickLoc
• Sealing: Viton O-ring for pressure differentials

Installation & Setup Guide

• Optimal Gap Setting: 1.0 mm (40 mils) from the target surface
• Mounting Torque: Maximum 0.56 N•m (finger tight is suitable)
• Thread Engagement: Maximum 12 mm for M8x1 thread
• Cable Bend Radius: Minimum 25.4 mm (1.0 inch)
• Target Size: Minimum 8.9 mm diameter, recommended 13 mm

System Integration & Compatibility

• This 3300 NSv probe offers full compatibility with older 3300 RAM systems
• It provides superior side-view characteristics and chemical resistance
• The system supports field wiring up to 305 meters (1000 feet)
• Use three-conductor shielded triad cable for best signal integrity

What You Will Receive

• One genuine Bently Nevada 330904-08-10-10-02-05 proximity probe
• All items are new and original from the manufacturer
• Secure factory packaging ensures product integrity during transit

Get the Complete Technical Details

Access the full datasheet for comprehensive system information. Download it here: Download 3300 XL NSv Datasheet.

Expert Answers to Common Questions

• What makes the NSv probe better for chemical environments?
  The probe tip uses PPS material and the cable has improved insulation for greater chemical resistance.
• How does the frequency response affect vibration measurements?
  The 10 kHz bandwidth accurately captures most machinery vibration frequencies without signal loss.
• What is the DC resistance specification for this probe?
  The resistance from center conductor to outer conductor is 4.2 ohms ± 0.5 ohms for the 1-meter version.
• Can I use this probe for axial position measurement on small shafts?
  Yes, but for shafts under 13 mm, reduce the gap setting to minimize scale factor changes.
• What is the capacitance of the extension cable?
  The typical capacitance is 69.9 pF per meter, which maintains signal quality over long runs.
