Bently Nevada – 21000-28-05-30-095-04-02 – Proximity Probe Housing Assembly

Product Overview

New Bently Nevada 21000-28-05-30-095-04-02 probe housing. Comes in factory packaging. 1-year warranty. Meets API 670 safety standards for hazardous areas.

Key Codes Explained for 21000-28-05-30-095-04-02

28-05-30-095-04-02:

A: 28 = 8mm probe
B: 05 = 0.5m (20″) cable
C: 30 = 3″ standoff
D: 095 = 9.5″ depth (±0.5″)
E: 04 = 1x 3/4-14 NPT plug
F: 02 = 3/4-14 NPT threads

Key Features

– Aluminum body with steel sleeve
– Weighs 2.4 lbs (1.1kg)
– Works in temps up to 125°C
– IP66 weather protection
– CSA & API 670 certified

Installation Guide

Required for this model:
✔ Add sleeve support (total depth 12.5″ >12″)
✔ Check probe label visibility (C+D=12.5″)
✔ Use ±0.5″ adjustment range

What’s Included

Dome cover, probe sleeve, O-rings, thread seal, reverse-mount probe. Optional 3/4-14 NPT fittings included.

Safety Certifications

Approved for Class I/II hazardous areas. Meets CSA Type 4 and API 670 standards for oil/gas use.

Warranty

12-month defect coverage. Free help with setup and API compliance checks.
