Allen-Bradley 25B-V6P0N104 PowerFlex 525 Drive – Compact & Smart Motor Control

Control your motors with precision using the Allen-Bradley 25B-V6P0N104. This 1.5HP (1.1kW) AC drive works with 120V single-phase input and delivers 6.0A output for smooth speed control.

Technical Details

• Model: 25B-V6P0N104 (PowerFlex 525 Series)
• Input: 100-120V AC, 1-Phase, 3.2A
• Output: 0-230V AC, 3-Phase, 6.0A
• Power: 1.5HP (1.1kW)
• Frequency: 0-500Hz adjustable
• Frame: B (Compact size)
• Safety: Safe-Torque-Off (STO) included
• Cooling: Air-cooled

Wiring & Connections

• 6 digital inputs
• 2 analog inputs (0-10V/0-20mA)
• 2 relay outputs
• 1 analog output
• Ethernet/IP port

What’s Included

• 25B-V6P0N104 Drive unit
• Mounting screws
• Quick start guide

Warranty & Shipping

12-month warranty. Ships via FedEx, UPS, or DHL with tracking.

Expert FAQs

• Q: Can this drive run a 3-phase motor from single-phase power?
  A: Yes! It converts 1-phase input to 3-phase output.
• Q: Does it work with Allen-Bradley PLCs?
  A: Yes, connects easily to CompactLogix and ControlLogix.
• Q: What’s the difference between V/Hz and Vector control?
  A: V/Hz is simpler, Vector gives better torque at low speeds.
• Q: Can I add an EMC filter later?
  A: No, this model doesn’t support external EMC filters.
• Q: How do I program the drive?
  A: Use the built-in keypad or connect via Ethernet.
