Allen-Bradley 22B-D017N104 PowerFlex 40P AC Drive

Allen-Bradley 22B-D017N104 PowerFlex 40 Drive – 10HP 480V VFD

Heavy-Duty Motor Control

• 10HP (7.5kW) industrial power for demanding applications
• Handles 380-480V AC 3-phase input power
• High 17A output for tough motor loads
• Built-in RS485 communication for easy control
• Compact panel-mount design

Technical Specifications

• Model: 22B-D017N104 (PowerFlex 40 series)
• Input Current: 24A at 480V
• Control: Sensorless Vector with PID
• Protection: 150% overload for 60 seconds
• I/O: 7 digital inputs, 3 analog inputs, 3 outputs
• Braking: Built-in IGBT brake
• Display: LCD with LED indicators

Installation & Support

• 12-month warranty
• Fast shipping via FedEx/UPS/DHL
• Works with pumps, conveyors, mixers
• Requires 24A circuit protection

Advanced Features

• Removable keypad for remote mounting
• Adjustable PWM for quiet operation
• Power loss ride-through (0.5-2 seconds)
• Network ready (DeviceNet, Ethernet/IP options)

Professional Questions

• What’s the minimum wire size required?
  Use 10 AWG or larger for 17A output.
• Can I use this for a crane application?
  Yes, excellent for lifting with high starting torque.
• Is the display readable in sunlight?
  Yes, high-contrast LCD works in bright light.
• What’s the maximum cable length for RS485?
  Up to 1200m (4000ft) with proper cabling.
• Does it support MODBUS RTU?
  Yes, via the RS485 interface.
