330102-00-40-10-11-05 Bently Nevada | 3300 XL 8mm Proximity Probe

Bently Nevada 3300 XL 8mm Proximity Probe: Precision Vibration Monitoring

New USA-made probe (330102-00-40-10-11-05) with 12-month warranty. Features FluidLoc cable and hazardous area certifications. Ships globally via FedEx/UPS/DHL.

TECHNICAL SPECIFICATIONS

PERFORMANCE DATA

• Temp Range: -34°C to +177°C (avoid below -34°C for seal)
• Max Wiring: 305m (1,000 ft) to monitor
• Thread Engagement: 14.3mm max (0.563 in)
• Pressure Seal: Viton O-ring (not factory tested)

INSTALLATION GUIDE

• Set gap at 1.27mm (50 mils) for vibration
• Use 3-conductor shielded triad cable
• Maintain minimum bend radius: 25.4mm
• Avoid temperatures below -34°C

CERTIFICATIONS

• CSA/ATEX/IECEx approved
• Class I Zone 0: AEx/Ex ia IIC T1-T5
• Class I Div 2: Groups A,B,C,D

PACKAGE CONTENTS

• 8mm proximity probe with 1m cable
• ClickLoc connector with protector
• Mounting hardware
• 12-month warranty documentation

FAQ

Q: What’s the measurement range?
A: 0.25-2.3mm linear range (10-90 mils).

Q: Is it suitable for Zone 0 areas?
A: Yes, certified for Class I Zone 0 hazardous locations.

Q: Can I use longer cables?
A: Supports up to 305m field wiring with signal rolloff at high frequencies.

Q: Is pressure testing included?
A: Not factory tested – contact for custom validation.
