330101-00-08-20-12-CN | Bently Nevada 3300 XL 8 mm Proximity Probe

Bently Nevada 3300 XL 8mm FluidLoc Vibration Probe

🔍 Model & Configuration

330101-00-08-20-12-CN features:
• 00: 0.0″ unthreaded section
• 08: 0.8″ compact case (shortest option)
• 20: 2.0m cable (6.6ft)
• 12: Built-in FluidLoc leak-proof cable
• CN: Country-specific certification

🛡️ Industrial-Grade Protection for 330101-00-08-20-12-CN

• 8mm armored tip resists impacts
• 330N (75 lbf) cable grip strength
• 1-year warranty (Made in USA)
• Optional COO certificate
• 323g/m lightweight design

🌡️ Extreme Environment Ready

• Works at -62°F to +500°F
• 7.88Ω ±0.5Ω resistance (2m system)
• 3% max humidity effect (56-day test)
• Avoid below -30°F for seal safety

🔧 Quick Installation

• Best gap: 1.27mm (50 mils)
• 16-24 AWG wires supported
• Stainless steel body (AISI 303/304)
• 200mV/mil output (±5% accuracy)

⚠️ Key Notes

• CN-certified for regional compliance
• FluidLoc blocks oil leaks in machines
• 69.9pF/m cable capacitance
• Viton® O-ring seal (custom pressure test available)
