3300 XL 8mm Proximity Probe Bently Nevada | 330106-05-30-05-02-00

Bently Nevada 3300 XL 8mm Reverse Mount Probe

Key Technical Specs

• Output signal: -18V to -20V DC
• Accuracy: ±0.75% full scale
• Temperature range: -40°C to +150°C
• Resistance: 7.45Ω ±0.50
• Vibration resistance: 10g RMS
• Frequency range: 0-12kHz

Model Code Breakdown (330106-05-30-05-02-00)

• 330106: Core probe model
• 05: Triaxial cable type
• 30: M10x1 thread size
• 05: 0.5 meter cable
• 02: ClickLoc connector
• 00: No agency approvals

Quick Installation

• Max thread depth: 15mm
• Install torque: 8.5-10.5 Nm
• Keep cable dry during setup
• Test resistance after install

System Compatibility

• 3300 XL monitoring units
• ClickLoc extension systems
• All 8mm probe adapters

Package Includes (330106-05-30-05-02-00)

• Probe with 0.5m cable
• Mounting hardware kit
• Protective end cap
• 12-month warranty

Fast Shipping Options

• FedEx Priority Overnight
• UPS Worldwide Express
• DHL Express
