140CRP93200 – Schneider Electric – RIO Adapter | Quantum PLC

Redundant Network Hub: Schneider Electric 140CRP93200 Adapter

Reliable RIO Head-End Solution

• The 140CRP93200 provides robust network connectivity with redundancy.
• This Schneider Electric adapter ensures continuous remote I/O operation.
• It supports extensive networks with up to 31 drops maximum capacity.
• You get dual F-type connectors for redundant cable configurations.
• The module delivers high-speed data transmission at 1.544 Mbit/s.
• Your remote I/O networks maintain operation even during cable failures.
• System reliability reaches maximum levels with this redundant design.

Technical Specifications

• Brand: Schneider Electric
• Model: 140CRP93200
• Product Type: RIO Head-End Adapter
• Network Capacity: 31 drops maximum
• I/O Capacity: 64 inputs/64 outputs per drop
• Transmission Speed: 1.544 Mbit/s
• Cable Type: 75 Ohm coaxial standard
• Dynamic Range: 35 dB signal quality
• Isolation Voltage: 500 V DC center to ground
• Connectors: 2 female F-type elbowed
• Power Consumption: 3 watts for 2 channels
• Bus Current: 750 mA requirement
• Impedance: 75 Ohm characteristic
• Return Loss: > 25 dB minimum
• Insertion Loss: < 0.2 dB per connector

System Compatibility

• Modicon Quantum 200 series
• Quantum 500 series systems
• Quantum 800 series platforms
• Symax mixed configurations
• Various I/O module types
• Multiple network topologies

Redundant Features

• Dual connector design
• Redundant cable support
• Automatic failover capability
• Continuous operation
• Fault tolerance
• High availability

Diagnostic Capabilities

• Memory check diagnostics
• LAN controller verification
• Power-up self-test
• Runtime monitoring
• Fault detection
• Status reporting

Environmental Specifications

• Operating temperature: 0°C to 60°C
• Storage temperature: -40°C to 85°C
• Humidity tolerance: 95% non-condensing
• Maximum altitude: 5000 meters
• ESD protection: 4kV contact, 8kV air
• EMC immunity: 10V/m 80-1000MHz

Physical Characteristics

• Standard module format
• Compact design
• Robust construction
• Industrial durability
• Easy installation
• Space-efficient layout

Shipping & Service

• Single unit packaging
• Package weight: 531 grams
• Dimensions: 31cm × 16.5cm × 5cm
• FedEx, UPS, DHL shipping
• 12 month warranty coverage
• Quality guaranteed

Technical Questions

• How many network drops does it support?
• The adapter supports networks with up to 31 drops for extensive I/O systems.
• What is the purpose of dual connectors?
• Dual connectors provide redundant cable paths for continuous operation during failures.
• What systems are compatible with this adapter?
• It works with Quantum 200/500/800 series and Symax systems in any mix.
• What is the data transmission speed?
• The module operates at 1.544 Mbit/s for high-speed remote I/O communication.
• What diagnostic features are included?
• It provides memory checks, LAN controller verification, and power-up diagnostics.
